The Cooling Fan (EV2; EV3) 3610PS-23T-B30-A00 MINEBEA is a high-performance cooling device designed for industrial electronic systems and automation control panels.
1. Detailed Specifications
- Sell Unit of Measure: EA
- Code: 09225PB-B3L-EA-01
- Integrated with Controller model: FS100
- Packaged Weight: 0.28 kg
- Packaged Length: 9.14 cm
- Packaged Width: 9.27 cm
- Packaged Height: 2.67 cm
- Bearing Type: Ball Bearing
- Current (A): 0.07 A
- Fan Speed (RPM): 3100 rpm
- Frequency (Hz): 60 Hz
- Input Power (W): 10 W (±10% to -20%)
- Life Expectancy (L10): 100,000 hours at 25°C
- Max. Air Flow (CFM): 35 CFM
- Max. Air Flow (m³/min): 0.98 m³/min
- Max. Static Pressure (In H₂O): 0.24 in H₂O
- Max. Static Pressure (Pa): 60.9 Pa
- Noise (dB): 39 dB
- Nominal Voltage (V): 230 V
- Starting Voltage (V): 180 V
- Origin: Japan
- Manufacturer: MINEBEA
- Distributor: Robotnext Corp.
- Warranty: 12 months
2. Application of Cooling Fan (EV2; EV3) 3610PS-23T-B30-A00 MINEBEA
The Cooling Fan (EV2; EV3) 3610PS-23T-B30-A00 MINEBEA is integrated with the FS100 Controller model. Its durable construction and strong airflow ensure optimal temperature regulation, enhancing component lifespan and system reliability.
